PeRT 3 Eagle User Manual Version 1.6
LeCroy Corporation
19
Main Library Window
The Main Library window provides information on
the status of a test script through the box located just
left of the script name. An open box indicates that
the script is stored on the server. A solid green
square indicates that a copy of this script has been
retrieved from the server and is currently on the client
PC as well. A solid green square with an asterisk
indicates that the script has been modified but not yet
saved on the server. A solid green square with an
arrow indicates a test script which is currently
running. The orange highlight indicates the test
script(s) currently selected, or in other words the
scripts to which Main Library commands located
across the top of the window (View/Edit, Save,
Rename, Delete, Filter or Export) will be applied.
File Menu
The File Menu is accessed by clicking
the round button in the top left corner of
the main application window. Clicking
this button produces the display shown
on the right, and provides access to the
commands New, Import, Export and
Print.
New Hovering the cursor over the New icon
display a list of commands which
include the ability to create a New Test
Script or to create a New Test Pattern.
Clicking on these icons will create the
appropriate new document in new
window in the Test Development
section.
