Getting Started Manual

922561-00 Rev A

103

Quick Zoom

Quickly create a Zoom trace by either pressing the front panel Zoom button
or touching the Zoom button on the respective channel dialog.

Turning Off Zoom

Turn off a Zoom by either pressing the front panel Zoom button again.

OR

On the corresponding Zoom dialog, touch the Trace On
checkbox to remove the check mark and disable the zoom
trace.
