01/13

8

51293 Rev. 2

SECTION 1: GENERAL INFORMATION

1.1.

INSTRUMENT DESCRIPTION

The FB6001/2 Instrument is a Basic, Inbound, Outbound, and GTN instrument. The
instrument may be enhanced by adding either a 4-20mA or Relay module to the unit.

– Only one (1) module may be added to provide either a 4-20mA output or a

Relay module interface to control traffic lights.

The FB6001/2 Instrument is designed for a wide variety of truck, floor, hopper, and
tank scale applications.

The load cells interface with the Instrument through the Analog Interface Card.

An RS-232 interface allows for the transfer of data from the Instrument to a
computer and vice versa.

The two FB6000 Series instrument models are the

Desktop (FB6001)

and the

NEMA 4X Wall Mount (FB6002).

1.1.1.

Standard Features

1.8” LED alphanumeric display

Three (3) RS232 serial ports

One (1) Ethernet Port

Capable of formatting tickets

Three (3) USB Ports

Keypad Buttons, including the following:

0-9 keys, Enter, Red (stop), Green (go), Tare, In,

Out, Units, B/G/Net, Zero and Print.

Choice of either One (1) 20mA port or

one (1) Analog Relay Board.

1.1.2.

Accessories

PART NO.

DESCRIPTION

30919

4-20mA Analog Kit *

30920

Relay PCB Assy Kit *

25498

Mini USB Keyboard (87 key)

31036

Standard USB Keyboard (104 key)

15892

SVP/ Uninterruptable Power Supply (USB)

* Only one or the other of these accessories may be used in the FB6001/2 series instrument.
