01/13 74 51293 Rev. 2
Appendix I: Data Output
A. REMOTE DISPLAY OUTPUT
Data Format
<4><0>
NOTES:
1. Characters denoted by X are characters 0-9.
2. Leading zeroes are suppressed.
3. Polarity indication for a positive value is a space ( SP ).
−
Negative values are not transmitted.
4. Identifier code <4><0> = Gross weight .
−
Transmission is Gross Only.
5. Transmission for the DEMAND Mode occurs when a carriage return
(CR) Hex 0D is received.
B. CONFIGURE OUTPUT
FAIRBANKS DATA FORMAT
NOTES:
1. Characters denoted by G and T are characters 0-9.
2. Leading zeroes are suppressed.
3. Gross Weight Data = G
Tare Weight Data = T
Status Code (Word) A
Bit # X00 X0 X X.X X.XX X.XXX X.XXXX X.XXXXX
0 0 1 0 1 0 1 0 1
1 0 0 1 1 0 0 1 1
2 0 0 0 0 1 1 1 1
