Section 6: Serial Input / Output
01/13
57
51293 Rev. 2
6.5. PRINTER SETUP AND PROGRAMMING
NOTE:
The standard default configuration on the COM Ports to all
printers is set at
9600 Baud, 8 data bits, No Parity
, and
1 stop bit
.
6.5.1.
OKI ML420 Printer Settings (Serial)
•
For FB6001/2 Instrument Desktop and NEMA 4X SERIAL communications, use
cable
25932
or
14807
•
Serial printer only.
Cable
25932
Wiring for COM 1-3
BAUD
9600
PARITY
No
DATA BITS
8
STOP BIT
1
DB-9
INSTRUMENT
DESCRIPTION
WIRE
COLOR
DB-25 PRINTER DESCRIPTION
2
RxD
BR
2
TxD
3
TxD
R
3
RxD
4
DRT
O
6
DSR
5
SG
Y
7
SG
6
DSR
G
20
DTR
7
RTS
BL
5
CTS
8
CTS
BK
4
RTS
Cable
14807
Wiring for COM 1-3
RS232
COM 1
RS232
COM 2
RS232
COM 3
DESCRIPTION
DB-25
PRINTER
3
3
3
Transmit (Tx)
3
2
2
2
Receive (Rx)
2
5
5
5
Ground (GND)
7
SEL
EXIT
POWER
SHIFT
ALARM
LF
GROUP
Micro Feed
Down
FF/LOAD
Micro Feed
Up
ITEM
MENU
TEAR
SET
PARK
QUIET
TOF
SEL
MENU
