Appendix I: Data Output
01/13 75 51293 Rev. 2
B. CONFIGURE OUTPUT, CONTINUED
FAIRBANKS DATA FORMAT
Increment Size
Bit # Count By 1 Count by 2 Count by 5
3 1 0 1
4 0 1 1
5 Always Logic 1
6 Always Logic 0
7 Parity Bit
Status Code (Word) B
Status Code (Word) C
Bit # Description
0 Gross = 0 Net = 1
1 Positive = 0 Negative = 1
2 In Range = 0 Overcapacity = 1
3 No Motion = 0 Motion = 1
4 Lb = 0 Kg = 1
5 Always Logic 1
6 Normal = 0 Power Up = 1
7 Parity Bit
Bit # Description
0 Always Logic = 0
1 Always Logic = 0
2 Always Logic = 0
3 Normal = 0 Print Switch Pushed = 1
4 Always Logic = 0
5 Always Logic = 0
6 Normal = 0 Keyboard Tare = 1
7 Parity Bit
