B. configure output, continued – Fairbanks FB6002 INSTRUMENTATION User Manual
Page 78
Appendix I: Data Output
01/13
78
51293 Rev. 2
B. CONFIGURE OUTPUT, CONTINUED
CARDINAL 738 CONTINUOUS SCOREBOARD DATA FORMAT
NOTES:
1. W = Displayed weight
P = Polarity
+ = Positive weight
- = Negative weight
U = Units
lb = pounds
kg = kilograms
M = Motion or O = Overload
G = Gross; N = Net
SP = Space
2. Leading zeros are not suppressed.
WEIGHTRONIX DATA FORMAT
< >
NOTES:
1. < > = Space
M = Mode
G =Gross
T=Tare
N=Net
W = Displayed weight
U = Units
m = Motion
o = Overload
2. Leading zeros are suppressed.
