Section 1: General Information
01/13 10 51293 Rev. 2
1.3. TECHNICAL SPECIFICATIONS
PARAMETER SPECIFICATION
Model Desktop FB6001/2 and NEMA 4X Wall Mount FB6002
Load Cell Interface Analog Up to 16 ~ 1000 Ω load cells max; Excitation = 5vdc,
Or up to 8 ~ 350 Ω load cells max
Cell Capacity 1 thru 999,999
Cell Units lbs, kgs, tons, tonne
No. of Scales One (1) only
Resolution 10000d commercial
20000d non-commercial
Scale Capacity 100-300,000
Division Size 0.0001 thru 50
Units lbs, kgs, tons, tonne
Serial Input/ Output Three (3) RS232 COM Ports, one (1) Console Port, three (3) USB
Ports
Storage Up to 100,000 transactions
Auto Zero Tracking Selectable – Off, 0.5d, 1.0d, 3.0d
Motion Band Selectable – Off, 0.5d, 1.0d, 3.0d
Zero Range Selectable – 2%, 100%
ENVIRONMENTAL SPECIFICATION
Enclosure NEMA 12 desk mount; NEMA 4X wall mount
Operating Temperature 14°F to 104°F, (–10°C to 40°C).
Operating Humidity NEMA 12 non-condensing, not suitable for wash-down conditions.
POWER REQUIREMENTS SPECIFICATION
Incoming Voltage
Requirement •
Instrument has an Auto-switching power supply.
•
100 VAC to 130 VAC, 50Hz\ 60Hz
•
200 VAC to 260 VAC, 50Hz\ 60Hz
•
It is recommended to install a separate circuit from the circuit
panel to the outlet used.
•
There must not be more than 0.2VAC between AC neutral and
ground
Ground Requirements For proper performance, the ground should have no more than
3.0
Ω resistance to true earth ground.
Power Consumption Less than (<) 40 watts
ETL Listed Conforms to UL STD 60950-1.
CAN/CSA C 22.2 NO.60950-1-03.
Approvals CC# 12-099
MC# AM-5878
