Programming the outbound ticket format – Fairbanks FB6002 INSTRUMENTATION User Manual
Page 44
Section 5: Configuration Menu
01/13
44
51293 Rev. 2
5.4.5.
Programming the Outbound Ticket Format
Defined below is the structure and appearance of an
Outbound
ticket example.
This image shows the printed areas and other
defined elements of the Outbound Ticket.
– All grey markings are for illustration purposes only.
Actual image of an Outbound Ticket
(without any Inbound Ticket information).
X / Y axis
starting point.
This flow chart outlines
coordinates for each element
of the Outbound Ticket.
