Section 4: Programming

4.1. PROGRAMMING THE INSTRUMENT

*

When configured with the BASIC Format, the

IN key

becomes the

GROSS / PRINT button

, and the

OUT key

becomes the

TARE / PRINT button.

The

TARE

and

PRINT

keys become non-functional.

KEYS

FUNCTION

RED & GREEN LIGHT
INSTRUMENTS

Activates the Traffic Light function, if one is installed.

When in the Programming Mode, press the

RED

button to immediately

return to the Weight Display, except when modifying an entry. Exit the
Entry Mode or Audit Mode, then retry.

TARE

Pressing the

TARE

button manually establishes a Tare Weight.

IN & OUT BUTTONS*

Manually selects whether the weighment is

IN

- or

OUT

- bound.

Arrows

The

UP

and

DOWN ARROWS

navigate through the menu selections.

These keys also modify numbers by increasing or decreasing the value

accordingly.

MENU

The

MENU

button initiates the programming process into the different menus.

It backs up one level on the Menu Tree .

If the

ENTER

button is not pressed to save the selected option, pressing the

MENU

button voids this input..

Numeric Keys

The

NUMERIC KEYS

enter values for passwords, weight amounts, and

configuration inputs.

These keys (alphanumeric with a keyboard) can shortcut to desired entries in

a selection item (see 5.1.2.Short-cut Method for Menu Navigations).

ENTER

Press

ENTER

to activate and save any data input.

UNITS

The

UNITS

button toggles and sets the unit types for the weight displayed.

Inserts data if additional items are needed. Data-insert function happens after the
item that is currently being viewed.

B/G/NET

The

B/G/NET

key initiates the Gross/Tare/Net function.

This key prints the

ticket printing configuration while in the Format

Menu.

B/G/NET

deletes one character in text/number.

ZERO

This button

ZERO

s the scale.

When editing numbers or text,

ZERO

will clear the data.

PRINT*

The

PRINT

key initiates a print cycle.

PRINT

toggles between editing and showing the name of the current menu.
