01/13 15 51293 Rev. 2
Section 3: User Operations
3.1. FRONT PANEL KEY FUNCTIONS
KEYS FUNCTION
RED & GREEN
LIGHT
INSTRUMENTS •
Activates the Traffic Light function, if one is installed.
•
When in the Programming Mode, press the RED button to immediately
return to the Weight Display, except when modifying an entry.
TARE Pressing the TARE button performs an AutoTare.
IN & OUT BUTTONS Manually selects whether the weighment is IN - or OUT - bound.
Arrows The UP and DOWN ARROWS navigate through the menu selections.
MENU •
The MENU button initiates the programming process into the different
menus, and is the basic Home button.
•
It backs up one level on the Menu Tree .
•
If the ENTER button is not pressed to save the selected option,
pressing the MENU button voids this input..
Numeric Keys •
The NUMERIC KEYS enter values for passwords, weight amounts,
and configuration inputs.
•
These keys (Alpha with a keyboard) can shortcut to desired entries in a
selection item (see 5.1.2.Short-cut Method for Menu Navigations).
ENTER Press ENTER to activate and save any data input.
UNITS •
The UNITS button toggles and sets the unit types for the weight
displayed.
•
When programming, it inserts data if additional items are needed.
•
Data-insert function happens after the item that is currently being
viewed.
B/G/NET •
The B/G/NET key initiates the Gross/Tare/Net function.
• BG/NET key prints the ticket printing configuration while in the
Format Menu.
• B/G/NET deletes one character in text/number.
ZERO •
This button ZERO s the scale.
•
When editing numbers or text, ZERO will clear the data.
PRINT •
The PRINT key initiates a print cycle.
• PRINT toggles between editing and showing the name of the current
menu choice
