Hardware Installation
2-18 Avaya Wireless AP-3 User’s Guide
6. Angle the antenna adapter slightly upwards, pinch the end tabs
inwards and carefully slide the antenna adapter onto the mounting
bracket.
7. Gently push forward while rotating the antenna downwards and
clip the adapter into the small cutouts on the face of the mounting
bracket.
8. Position the antenna for best reception:
— at a 90° angle for flat surface mounts
— at a 180° angle for wall mounts
9. Re-install the cover and mount the AP back in place.
Figure 2-12. Replace cover
10. Connect the power and Ethernet cables to the AP.
