25 9900-1BC Batch Controller Manual
General
Input channels:
One
Enclosure and Display
Case Material:
PBT
Window: Shatter-Resistant Glass
Keypad: 4 buttons, injection-molded
silicone rubber seal
Display: Backlit, 7- and 14-segment
Indicators “Dial-type” digital bar graph
Update rate: 1 s
LCD Contrast: 5 settings
Enclosure
Size
¼ DIN
Color Black
Mounting
Panel
¼ DIN, ribbed on four sides
for panel mounting clip
inside panel
Wall Large enclosure
(sold as an accessory) that
encases the transmitter
Specifi cations
Environmental Requirements
Ambient operating temperature:
Backlit LCD:
-10 °C to 70 °C
(14 °F to 158 °F)
Storage Temp: -15 °C to 70 °C
(5 °F to 158 °F)
Operating Temp -10 °C to 70 °C
(14 °F to 158 °F)
Relative Humidity: 0 to 100% condensing for
front only;
0 to 95% non-condensing
for back side.
Maximum Altitude: 4,000 m (13,123 ft)
Enclosure Rating: Designed to meet
NEMA 4X/IP65
(front face only).
Performance Specifi cations
Accuracy ±0.2%
System Response:
• Primarily dependent upon the sensor. Transmitter
adds a maximum 150 ms
processing delay of the sensor electronics.
• Minimum update period is 100 ms.
• System response is tempered by the display rate.
