BEI Sensors MHK5 Absolute Hollow Shaft Encoder User Manual
Page 59

Version 07/10
BEI Sensors CANopen Manual serie M
59
Hollow shaft (B)
* Edelstahl / Stainless steel
20
°
Ø63
20
72
Single-Turn=100 , Multi-Turn=112
1,3
3,3
Anlagekan
te
an Mom
en
tenstü
tze
Ø15
F7
15
23
Ш59 (Ш61)*
~32
Ш6,5-9
Schlüsselweite, wrench size=17
Ш3,2
63,5
20
20
Ш60
(la
y-on ed
ge
torque suppo
rt)
** Welleneinstecktiefe (hollow shaft depth)
Max. W ** = 30
Min. W ** = 15
Mounting instructions
The clamp ring may only be tightened if the shaft
of the driving element is in the hollow shaft.
The diameter of the hollow shaft can be reduced to
12mm, 10 mm or 8 mm by using an adapter (this
reducing adapter can be pushed into the hollow
shaft).
Allowed shaft movements of the drive element are
listed in the table.
axial
radial
static
± 0.3 mm
± 0.5 mm
dynamic
± 0.1 mm
± 0.2 mm
Single-Turn = 90, Multi-Turn = 102
