Object 3021h: acceleration value, Object 3030h: c2-c5-behavior, Object 4000h: bootloader control – BEI Sensors MHK5 Absolute Hollow Shaft Encoder User Manual
Page 43

Version 07/10
BEI Sensors CANopen Manual serie M
43
0h
Number of sub indices
Unsigned 8
2h
Ro
1h
Enable Acceleration
Unsigned 8
0h
rw
Yes
2h
Acceleration modus
Unsigned 8
0h
rw
yes
Object 3021h: Acceleration Value
This object contains acceleration value.
Subindex Description
Data Type
Default Value
Access
Restore after
BootUp
0h
Acceleration Value
INTEGER32
romap
Acceleration-modus setting
Delay [msec]
Accuracy [steps/sec²]
0
1
2
40
120
750
+/-1’024
+/-512
+/-128
Tab. 21 Delay and accuracy
Object 3030h: C2-C5-Behavior
This object allows to switch back in an backward compatibility mode. To switch back, the security code
“47111147h“ has to be written to Subindex 0h. After this the Subindex 1h Enable C2-C5-Behavior can be
written to ONE. This modus should only be used for fully compatible replacement of C2- or C5-encoders.
For further information, concerning compatibility, have a look at Apendix B
Subindex Description
Data Type
Default Value
Access
Restore after
BootUp
0h
Security code
Unsigned 32
47111147h
ro
1h Enable
C2-C5-Behavior
BOOL 0h
rw
yes
Object 4000h: Bootloader Control
This object controls the Bootloader functionality. Writing the security code to this object causes erasing the
EEPROM and application information in the flash memory and resets the device. After a power-up, the
Bootloader checks the user application and detects no more information. The Bootloader starts up with a
pre-defined CANopen node ID of 1 (0x1) and a fixed CAN baud rate of 125 kbits.
