Example 6
The example below (figure 51) shows how you can use JavaScript to parse the response
from an Extron matrix switcher and produce a formatted Web page.
Example 6
<br>xOut1 = "";<br>xOut2 = "";<br>xOut3 = "";<br>xOut4 = "";<br>
Sample links that can be followed
http://192.168.254.254/example#6.html?cmd=W01RS|5*1! -Creates tie from input 5 to output 1
http://192.168.254.254/example#6.html?cmd=W01RS|1*2! -Creates tie from input 1 to output 2
Response to last URL encoded command:
____________Unformatted Response:
Output 1 Setup:
Output 2 Setup:
Output 3 Setup:
Output 4 Setup:
____________Formatted Response:
<br><br>
Figure 51. HTML Source Code Using JavaScript to Display Matrix Switcher
Responses
Figure 52. Browser View
IPL T SFI244 • Communication and Control 50
