X2#
= Priority status for receive timeout: 0 = priority set to Send Data String command parameters,
1 = priority set to configure received timeout command parameters
X2%
= Baud rate: 300, 600, 1200, 1800, 2400, 3600, 4800, 7200, 9600, 14400, 19200, 28800, 38400,
57600, 115200
X2^
= Parity: Odd, Even, None, Mark, Space (only first letter is required)
X2&
= Data bits: 7, 8
X2*
= Stop bits: 1, 2
X2(
= Port type: RS-232, RS-422, RS-485 (or 0, 1, or 2, respectively). ( X2( = 0 for the SFI244)
X3)
= Flow control: Hardware, Software, None (only first letter is required)
X3!
= Data pacing (specified in milliseconds between bytes): 0000-1000 (default = 0 milliseconds)
X3#
= Password: maximum length of 12 characters and no special characters.
NOTE: User password cannot be assigned if no administrator password exists, and returns
E14. If the administrator password is cleared, then the user password is also removed.
X3$
= Daylight saving time: 0 = off/ignore; 1 = on (use in northern hemisphere) (USA); 2 = on (Europe);
3 = on (Brazil)
X3%
= Event number: range = 0 - 99 (max.)
X3^
= Event buffer: 0 = receive; 1 = user (absolute); 2 = user (relative); 3 = NVRAM
X3&
= Event buffer offset: range = 0 - MaxBufferSize
X3*
= Event data size: bit; Byte (8-bit); Short (16-bit); Long (32-bit) (only first letter is required)
NOTE:
This parameter is case-sensitive.
X3(
= Event data to write.
X4)
= I/O mode: 0 = input; 1 = output; 2 = input plus pull-up resistor; 3 = output plus pull-up resistor;
4 = analog in; 5 = analog in w/pull-up; 6 = adjust in (requires X5% &
X5^
thresholds); 7 = adjust in
w/pull-up (requires X5% &
X5^
thresholds). X5% &
X5^
thresholds are not required for modes 0-5.
X4#
= 0 = off; 1 = on; value = 0-4095, based on 12-bit A to D
X4$
= Number of bytes to read
X4%
= E-mail recipient number: range = 1 - 64 max
X4^
= E-mail recipient address: maximum number of characters for a full e-mail address is 31 characters.
X4&
= Name of e-mail file to be sent: the first line of the file is the subject, the rest is the body of the e-mail.
NOTE:
E-mail files must have the .eml file extension.
X4(
= Default Name: Combination of model name and last 3 pairs of MAC address (for example,
IPL-T-SFI244-00-02-3D)
X5)
= Redirect: 0 = no redirect; 1-n = redirect serial port from the specified port to allow for a transparent
pass-through mode
X5@
= Connection’s security level: 0 = not logged in; 11 = user; 12 = administrator
X5#
= Timeout for data pass-through mode, after which event data can be inserted into the transmit buffer.
X5$
= ASCII digit(s) representing numeric value of data element read from event buffer (leading zeros are
suppressed)
X5%
= Upper transition threshold (0 detection = off) for digital inputs; Lower must be smaller than upper
(0-4095 based on 12-bit A to D)
X5^
= Lower transition threshold (1 detection = on) for digital inputs; Lower must be smaller than upper
(0-4095 based on 12-bit A to D)
NOTE: The default Web pages display X5% and X5^ as voltages (100 mV to 24 VDC, upper
default = 2 VDC and lower default = 1 VDC). The conversion rate is 162 counts to
1 V.
X5&
= IR playback file number (0-99)
X5*
= IR function number
X5(
= IR playback mode: 0 = play once, 1 = play continuously (send IR command again with mode = 0 to
stop mode 1 playback)
IPL T SFI244 • Communication and Control 34
