the LED is not lit, the connection speed is 10 Mbps.

h

Link LED — A green LED indicates that the unit is connected to an active network.

i

Act (Activity) LED — A yellow LED lights to indicate that data is being sent or

received.

Resetting the Unit

There are five reset modes available by using the Reset button (

b

) on the front panel. The

Reset button is recessed, so use of a pointed stylus, ballpoint pen, or Extron Tweeker is
suggested.

CAUTION: Review the reset modes carefully. Use of the wrong reset mode may result

in unintended loss of flash memory programming, the reassignment of
ports, or a unit reboot.

IPL T SFI244 • Installation and Operation

9
