AVT 200HD Tuner • Remote Configuration and Control 59
Command/Response Table for IP-Specific SIS Commands
Command
ASCII Command
(Host to Tuner)
Response
(Tuner to Host)
Additional Description
Bidirectional Serial Port
Send data string
EX4! * X5& * X5* * X6! RS } X4@ response from command ]
Configure port parameters 24 EX4! * X6% , X6^ , X6& , X6* CP }
Cpn X4! • X6% , X6^ , X6& , X6*]
Set baud rate X6% , parity X6^ ,
X6& data bits, and X6* stop bits
for port X4! .
X6% = 9600, 19200, 38400, or
115200 (default = 9600)
X6^ = odd, even, none, mark,
or space. (Only the first letter is
required.)
X6& = Data bits: 7 or 8
(default = 8)
X6* = Stop bits: 1 or 2
(default =1)
View port parameters EX4! CP } X6% , X6^ , X6& , X6*]
Configure flow control 24 EX4! * X7) , X7!} Cpn X4! •Cfl X7) , X7!] Set flow control type X7) for
port X4! with X7! ms between
bytes. For X7) :
H = Hardware
S = Software
N = None (default)
X7! = 0000 through 0001
(default = 0 ms)
View flow control EX4! *CF } X7) , X7!]
Configure receive timeout 24 E X4!
*
X5&
*
X5*
*
X6#
*
X6! CE }
Cpn X4! •Cce X1& , X5* , X6# , X6! CE ]
NOTE: X5& = Time in tens of milliseconds that the AVT will wait until receipt of the first response character before
terminating the command. (Default = 10 = 10 ms; max. = 32767.)
X5* = Time in tens of milliseconds that the AVT will wait between characters being received via a serial port before
terminating the current command or receive operation. (Default = 20 = 20 ms; max. = 32767.)
X6! = #L or #D. The letter parameter is case sensitive (requires capital D or capital L). For X6! :
L = Length of the message to be received,
D = Delimiter value. A delimiter of ASCII 0A = 10D.
# = Byte count (for L) or a single ASCII character expressed in decimal form (for D).
Byte count # can be 0 through 32767; default = 0. The ASCII decimal # can be 0 through 00255;
default = the byte count. A 3-byte length = 3L. The response includes leading zeros.
X6# = Priority Status for port X4! receiving timeouts. For X6# :
0 = Use Send data string command parameters (default);
1 = Use Configure receive timeout command parameters. The response includes leading zeros.
View receive timeout EX! CE } X5& , X5* , X6# , X6! ]
Ethernet Data Port
Set current connection port
timeout
E 0* X9( TC } Pti0* X9(] Set number of seconds (in tens
of seconds) before timeout on IP
connections.
X9( = 1 through 32767.
View current connection port
timeout E 0TC } X9(]
Set global port timeout E 1* X9( TC } Pti1* X9(]
View global port timeout E 1TC } X9(]
