AVT 200HD Tuner • Reference Information

100

100

IP Addressing

What is an IP Address?

An IP address is a 32-bit binary number that is used to identify each device on an Ethernet
network. This number is usually represented by four decimal numbers (each in the range
or 0 to 255) separated by dots, such as 198.123.34.240. This is called “dotted decimal
notation.”
An IP address is divided into two parts:

Network identifier

Host identifier

Each address on a given network must have the same network identifier value but have
a unique host identifier. As a result, there are different classes of addresses the define the
range of valid addresses and which parts of the address are used for the network and host
identifiers.
The most common IP address classes are:

Class Name

Valid Address Range

Identifier Arrangement

Class A

0.0.0.1 to 127.255.255.254

NNN.HHH.HHH.HHH

Class B

128.0.0.1 to 191.255.255.254

NNN.NNN.HHH.HHH

Class C

192.0.0.1 to 223.255.255.254

NNN.NNN.NNN.HHH

NNN

refers to the network identifier and

HHH

refers to the host identifier.

Choosing IP Addresses

If the computer and the AVT are directly connected or connected via their own independent
network, follow the guidelines below for choosing the IP addresses.
However, if you intend to connect your computer and tuner to an existing network, you
need to advise the network administrator and ask the administrator to allocate suitable IP
addresses.
On an independent network, it is generally recommended that you use the Class C format
(from 192.0.0.1 to 223.255.255.254).
There are two rules for choosing IP addresses:

Network identifier must be the same for each IP address

Host identifier must be unique for each address.

Applying these rules to Class C addresses, the first three decimal values of your IP address
must all be the same while the last value is used to uniquely identify each device.
The following is an example of a valid Class C addressing scheme:

Device

IP Address

AVT 200HD Control Software Computer

208.132.180.41

AVT 200HD tuner

208.132.180.42

NOTE: The host identifiers (41, 42, and 43 in the above example) do not need to be

sequential or in any particular order. However, it is recommended that you
group the numbers for simplicity.
