AVT 200HD Tuner • Remote Configuration and Control 56
Symbol Definitions for IP-specific Commands
X4!
= Port number 01–99 (represented as two ASCII characters with
leading zero if required
X4@
= Command data section Factory default name (model name + last 3 pairs of
MAC address)
X4#
= GMT offset –12.0 through +14.0. Represents hours and minutes
offset from Greenwich mean time (GMT).
X4%
= On and off status 0 = off or disabled
1 = on or enabled
X4^
= Dirty RAM status 0 = Random access memory has been saved to flash
memory (OK to power off or reset).
1 = RAM needs to be saved to flash memory
X5!
= Firmware version number n.nn (listed to two decimal places)
X5@
= Unit name Up to 24 characters: alphabetical (A–Z or a–z), digits
(0–9), or hyphen (-).
NOTES: • The following characters are invalid or not recommended in names:
{space} + ~ , @ = ` [ ] { } < > ‘ ’ “ ” ; : | \ and ?.
• The first character must be alphabetical.
• The last character must not be a hyphen.
X5#
= Local date and time format For setting:
In the format MM/DD/YY•HH:MM:SS
MM = month: 10 (January) through 12 (December)
DD = 01 through 31
YY = 00 through 99
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
For reading:
In the format Day,•DD•Mmm•YYYY•HH:MM:SS:
Day = weekday: Mon through Sun
DD = 01 through 31
Mmm = month: (Jan through Dec)
YYYY = year: 2000 through 2099
HH = 00 through 23
MM = 00 through 59
SS = 00 through 59
X5$ = IP address nnn.nnn.nnn.nnn
(Leading zeros in each of the four fields are optional
for setting values and are suppressed in returned
values.
Factory default address: 192.168.254.254
Default broadcast IP address: 255.255.255.255
X5^
= Power-up delay between ports in 1 through 255.
1/3 second increments. Default = 3, or 1 second.
X5&
= Time (in 10-ms increments) to wait 10 through 32767
for characters to come into a serial Default = 10, or 100 ms
port before terminating the
connection
X5*
= Time (in 10-ms increments) to wait 2 through 32767
between characters before Default = 2, or 20 ms
terminating the connection
X5(
= Hardware (MAC) address 00-05-A6-xx-xx-xx
