AVT 200HD Tuner • Operation

15

Powering On

Apply power by connecting the provided IEC power cord to the rear panel IEC connector
and to an AC source. The tuner performs a self-test that flashes the three TV format
indicators in order from top to bottom and then turns them off while the initial two
power-up screens are displayed in the LCD screen. At the completion of the self-test, the LED
display shows the current channel, the appropriate TV format LED is lit, and the LCD window
displays the default screen cycle.
If an error occurs during the self-test, the AVT locks up and does not operate. If this
occurs, call the Extron S

3

Sales & Technical Support Hotline. See the rear cover for

contact

information

in your area.

When power is first applied to the AVT, the LCD screen displays

Extron Electronics

, then

AVT

200HD

with the current firmware version. If the AVT self-test completes successfully, the

default cycle begins, in which the display alternates between a screen showing the current
output resolution and refresh rates and a screen showing the channel to which the AVT is
currently tuned. These two screens continue to cycle on the screen when the menu system is
not in use.

NOTE: Audio and video mute settings are not retained when power is cycled to the

AVT.

The flow diagram on the next page shows the order in which the screens appear at
power-up.

Default Cycle

or

Power

On

AVT 200HD

VERSION 1.00

EXTRON

ELECTRONICS

OUTPUT

480i @ 59.94

NBC-LA

AIR 4-1

Preset01

AIR 4-1

Figure 13.

Power-up and Default Cycle Screens (Example)

NOTE: If your AVT 200HD is new and no channel scan

has been performed, the two screens shown at
right alternate on the LCD screen instead of the
default cycle (see “

Scanning for

channels

,” later in this section).

This cycle also appears after a system reset
(see “

Unit Reset Menu (Resetting from the

Front Panel)

,” later in this section.) After the

first scan the default cycle is displayed after power-up.

AIR CHANNEL

LIST EMPTY

PRESS UP BUTTON

TO START SCAN
