AVT 200HD Tuner • Remote Configuration and Control

50

Command

ASCII Command

(Host to Tuner)

Response

(Tuner to Host)

Additional Description

Video Output (continued)

Closed Captioning (continued)

View CC text fill

E

O FSCC

}

X1*]

Show the selected font fill.

Select CC background color

E

K

X1&

FSCC

}

FsccK

X1&]

Select background color

X1&

for

the closed caption. For

X1&

:

0 = white

1 = black (default)

2 = red

3 = green

4 = blue

5 = yellow

6 = magenta

7 = cyan

View CC background color

E

K FSCC

}

X1&]

Show the selected background
color.

Select CC background fill

E

T

X1*

FSCC

}

FsccT

X1*]

Select type of fill

X1*

for the

closed caption background. For

X1*

:

0 = solid (default)

1 = transparent

2 = translucent

3 = flashing

View CC background fill

E

T FSCC

}

X1*]

Show the selected background
fill.

Select CC text edge type

E

E

X2*

FSCC

}

FsccE

X2*]

Select text edge type

X2*

for the

closed caption. For

X2*

:

0 = none (default)

1 = raised

2 = recessed

3 = uniform

4 = left shadow

5 = right shadow

View CC text edge type

E

E FSCC

}

X2*]

Show the selected edge type.

Select CC edge color

E

D

X1&

FSCC

}

FsccD

X1&]

Select edge color

X1&

for the

closed caption. For

X1&

:

0 = white

1 = black (default)

2 = red

3 = green

4 = blue

5 = yellow

6 = magenta

7 = cyan

View CC edge color

E

D FSCC

}

X1&]

Show the selected edge color.

Audio Output
Set digital audio output
format

EX(

AFMT

}

Afmt

X(]

Select digital output type

X(

.

For

X(

:

1 = AC-3 (Dolby digital)

2 = PCM

View digital audio output
format

E

AFMT

}

X(]

Show the selected digital audio
output format.
