AVT 200HD Tuner • Remote Configuration and Control

44

X1&

= Closed caption foreground

0 = white

4 = blue

and background color

1 = black

5 = yellow

2 = red

6 = magenta

3 = green

7 = cyan

X1*

= Closed caption text

0 = solid

and background fill

1 = transparent

2 = translucent

3 = flashing

X1(

= Channel scan progress

0 – 100%

X2)

= Number of channels found

0 – 999

X2!

= Movie rating

0 = none

4 = R

1 = G

5 = NC-17

2 = PG

6 = X

3 = PG13

7 = NR

X2@

= TV rating

0 = none

4 = TV-PG

1 = TV-Y

5 = TV-14

2 = TV-Y7

6 = TV-MA

3 = TV-G

X2#

= Preset name

10 characters maximum

Upper- and lowercase alphanumeric characters are valid.

X2%

= Preset number

1 – 99

X2^

= Output resolution

0 = 480i @ 59.94 Hz

1 = 480p @ 59.94 Hz

2 = 720p @ 60 Hz

3 = 1080i @ 60 Hz

X2&

= Output polarity

0 = H- V-

1 = H- V+

2 = H+ V-

3 = H+ V+

X2*

= Closed caption edge type

0 = none

1 = raised

2 = recessed

3 = uniform

4 = left shadow

5 = right shadow

X2(

= Channel name

Up to 7 characters

X3)

= TV rating of current program

Up to 16 characters

X3!

= Signal strength

0 – 100%

NOTE: The following characters are invalid in names and other text:

{space} ~ , @ = ‘ [ ] { } < > ’ ’ “ ” ; : | \ and ?.

X3@

= V-chip (parental control)

Consists of 4 digits.

personal identification
number (PIN)

X3#

= Sudio mute status

0 = audio unmuted

1 = audio muted

2 = only S/PDIF audio muted
