MX350 AUTOMATIC TRANSFER CONTROL SYSTEM – INSTRUCTION MANUAL
9–1
MX350 Automatic Transfer Control
System
Chapter 9: Communications
Digital Energy
Multilin
Communications
Communications interfaces
The MX350 supports two communications interfaces:
•
Modbus RTU via RS485
•
Modbus TCP/IP via 10/100Base-T Ethernet
In addition, a USB interface is provided on the front of the interface panel. It is configured
to be used in conjunction with a virtual serial port on a Windows-based PC.
NOTE
NOTE:
Setpoint changes related to communication parameters require a power cycle of the
controller to be activated.
NOTE
NOTE:
For full details, please refer to the MX350 Communications Guide to be found at http://
www.gedigitalenergy.com/app/Resources.aspx?prod=zte&type=3 .
