178
AT8xC5122/23
4202E–SCR–06/06
Reset Value = XXXX X000b
The three lower bits (S0, S1, S2) located into WDTPRG register enables to program the
WDT duration.
To compute WD Timeout, the following formula must be applied:
Time Out = 6 * (2 14 * 2 Svalue - 1 ) / F
CK_WD
Note: Svalue represents the decimal value of (S2 S1 S0)
Table 109. Watchdog Timer Out Register - WDTPRG (0A7h)
7 6 5 4 3 2 1 0
- - - - - S2 S1 S0
Bit
Number
Bit
Mnemonic Description
7 - 3 -
Reserved
The value read from this bit is indeterminate. Do not change these bits.
2 S2 WDT Time-out select bit 2
1 S1 WDT Time-out select bit 1
0 S0 WDT Time-out select bit 0
Table 110. Machine Cycle Count
S2 S1 S0 Machine Cycle Count
0 0 0 2 14 - 1
0 0 1 2 15 - 1
0 1 0 2 16 - 1
0 1 1 2 17 - 1
1 0 0 2 18 - 1
1 0 1 2 19 - 1
1 1 0 2 20 - 1
1 1 1 2 21 - 1
