Features, Enhanced features

1
High-
performance
EE-based CPLD
ATF1516AS
ATF1516ASL
Preliminary
Features
•
High-density, High-performance, Electrically-erasable Complex
Programmable Logic Device
– 256 Macrocells
– 5 Product Terms per Macrocell, Expandable up to 40 per Macrocell
– 160, 192, 208 pins
– 10 ns Maximum Pin-to-pin Delay
– Registered Operation Up To 100 MHz
– Enhanced Routing Resources
•
Flexible Logic Macrocell
– D/T/Latch Configurable Flip-flops
– Global and Individual Register Control Signals
– Global and Individual Output Enable
– Programmable Output Slew Rate
– Programmable Output Open Collector Option
– Maximum Logic Utilization by Burying a Register within a COM Output
•
Advanced Power Management Features
– Automatic 3 mA Standby for “L” Version (Maximum)
– Pin-controlled 4 mA Standby Mode (Typical)
– Programmable Pin-keeper Inputs and I/Os
– Reduced-power Feature per Macrocell
•
Available in Commercial and Industrial Temperature Ranges
•
Available in 160-lead PQFP, 192-pin PGA, and 208-lead RQFP Packages
•
Advanced EE Technology
– 100% Tested
– Completely Reprogrammable
– 10,000 Program/Erase Cycles
– 20 Year Data Retention
– 2000V ESD Protection
– 200 mA Latch-up Immunity
•
JTAG Boundary-scan Testing to IEEE Std. 1149.1-1990 and 1149.1a-1993 Supported
•
Fast In-System Programmability (ISP) via JTAG
•
PCI-compliant
•
3.3 or 5.0V I/O Pins
•
Security Fuse Feature
Enhanced Features
•
Improved Connectivity (Additional Feedback Routing, Alternate Input Routing)
•
Output Enable Product Terms
•
D-latch Mode
•
Combinatorial Output with Registered Feedback within Any Macrocell
•
Three Global Clock Pins
•
ITD (Input Transition Detection) Circuits on Global Clocks, Inputs and I/O
•
Fast Registered Input from Product Term
•
Programmable “Pin-keeper” Option
•
V
CC
Power-up Reset Option
•
Pull-up Option on JTAG Pins TMS and TDI
•
Advanced Power Management Features
– Edge Controlled Power-down “L”
– Individual Macrocell Power Option
– Disable ITD on Global Clocks, Inputs and I/O
Rev. 0994D–09/99
