BA6283N / BA6955N
Motor driver ICs
Reversible motor driver
BA6283N / BA6955N
The BA6283N and BA6955N are reversible-motor drivers with a maximum output current of 1.0A. Two logic inputs allow
four output modes: forward, reverse, stop (standby), and brake.
The built-in power save circuit suppresses current consumption in the motor stop mode.
!
!
!
!
Applications
VCRs, audio devices
!
!
!
!
Features
1) Logic and driver sections have separate ground pins; this allows the IC to drive speed-variable, reversible motors by
connecting an electronic governor circuit.
2) Built-in power saving circuit suppresses current consumption in stop (standby) mode.
3) Interfaces with TTL devices.
4) Built-in thermal shutdown circuit.
!
!
!
!
Absolute maximum ratings (Ta = 25
°C)
Parameter
Symbol
Limits
Unit
Applied voltage
V
CC
18
V
Power dissipation
Pd
BA6283N
BA6955N
1150
∗
1
1080
∗
2
mW
Operating temperature
Topr
−
20~
+
75
°
C
Output current
I
OUT
1000
∗
3
mA
Storage temperature
Tstg
−
55~
+
150
°
C
∗
1 Reduced by 9.2mW for each increase in Ta of 1
°
C over 25
°
C.
∗
2 Reduced by 8.64mW for each increase in Ta of 1
°
C over 25
°
C.
∗
3 Should not exceed Pd or ASO values.
!
!
!
!
Recommended operating conditions (Ta = 25
°C)
Parameter
Operating power supply voltage
V
CC
5.5
15
V
−
V
M
5.5
15
V
−
Symbol
Min.
Typ.
Max.
Unit
