J300P-4
END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger/plug) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
7
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
SPL140 SERIES (Continued) E-5.457 IN. D-1.938 IN. USE KIT SPL140X
USE BEARING RETAINER NO. 140-70-18X
2.390-46 Involute Spline
2.390 3.250 2.323 5.660 .140 HR 5003557 5003552 140-4-301-1
5003557 was replaced by 140-4-03557-1X
2.390 3.250 2.323 5.660 .140 HR 140-4-03557-1X 5003552 140-4-301-1
2.390 3.250 2.323 5.660 .140 HR 140-4-311-1X 231803 140-4-301-1
2.390 3.312 2.750 5.374 .157 HR — — 140-4-1011-1
2.390 3.375 3.195 6.440 .580 HR 140-4-391-1X 232610 140-4-381-1©
2.390 3.500 3.375 5.920 — HR — — 140-4-751-1
2.500-10 Spline
2.500 3.750 3.000 5.960 — HR 140-4-1121-1X 231616 140-4-1111-1©
2.500 3.750 3.000 5.960 — HR 140-4-51-1X• 231616 140-4-41-1•
2.544-49 Involute Spline
2.544 3.750 3.000 5.570 — HR 140-4-151-1X• 231616 140-4-141-1©
2.544 4.000 2.750 6.060 .180 HR — — 140-4-881-1
2.750-10 Spline
2.750 3.750 3.000 6.570 — HR 140-4-71-1X 230902 140-4-61-1©
2.750 3.750 3.000 6.570 — HR 140-4-91-1X 231616 140-4-81-1©
2.794-54 Involute Spline
2.794 — 2.745 6.320 — HR — — 140-4-201-1
2.795-55 Involute Spline
2.795 4.725 2.047 4.980 .150 HR — — 140-4-771-1
SPL170 SERIES E-6.456 IN. D-2.166 IN. USE KIT SPL170-3X
USE BEARING RETAINER KIT NO. 170-70-18X
1.774-34 Spline
1.774 2.500 2.250 5.031 .090 HR 170-4-1751-1X — 170-4-621-1©
1.774 2.500 2.250 6.440 .090 HR 170-4-09705-1X 231101 170-4-631-1•
High angle yoke
1.774 2.500 2.250 6.440 .090 HR 5009705 231101 170-4-631-1•
5009705 was replaced by 170-4-09705-1X; High angle yoke
1.790-34 Involute Spline
1.790 2.500 2.250 5.030 .090 HR — — 170-4-921-1
1.790 2.625 2.438 5.600 .250 HR 170-4-121-1X• 232166 170-4-111-1•
1.790 2.625 2.438 6.250 .250 HR 170-4-141-1X 232166 170-4-131-1©
High angle yoke
1.943-37 Involute Spline
1.943 3.150 1.625 4.547 .090 HR — — 170-4-1971-1
1.989-30 Involute Spline
1.989 3.000 2.685 6.580 .220 HR — — 170-4-771-1
High angle yoke
1.998-38 Involute Spline
1.998 2.750 2.125 4.844 — HR — — 170-4-541-1
2.024-39 Spline
2.024 2.750 2.000 5.370 .120 HR 170-4-1261-1X 232042-2 170-4-1251-1
High angle yoke
2.024 3.000 2.312 5.090 .105 HR 170-4-701-1X 232182 170-4-641-1
2.024 3.000 2.312 5.090 .105 HR 170-4-681-1X 231102 170-4-641-1
2.024 3.000 2.312 5.090 .105 HR 170-4-651-1X 231359 170-4-641-1
2.024 3.000 2.312 6.391 .105 HR 170-4-691-1X 232182 170-4-661-1•
High angle yoke
2.024 3.000 2.312 6.391 .105 HR 170-4-671-1X 231359 170-4-661-1•
High angle yoke
