J300P-4
END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger/plug) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
9
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
SPL170 SERIES (Continued) E-6.456 IN. D-2.166 IN. USE KIT SPL170-3X
USE BEARING RETAINER KIT NO. 170-70-18X
2.143-41 Involute Spline (Continued)
2.143 2.938 3.000 7.190 .380 HR 131451K 232168 5008448
5008448 was replaced by 170-4-08448-1X; Attach nut #128049 for Spicer Axles only
2.178-43 Involute Spline
2.178 3.540 2.050 5.340 .157 HR — — 170-4-1081-1•
2.225-6 Spline
2.225 3.000 3.250 6.030 — HR — — 170-4-1441-1
2.250-10 Spline
2.250 3.500 3.000 5.750 — HR 170-4-461-1X• 231616 170-4-451-1
2.274-44 Involute Spline
2.274 2.938 2.350 5.094 — HR 170-4-31-1X 232604 170-4-21-1©
2.274 2.938 2.500 5.281 — HR 170-4-101-1X• 232168 170-4-91-1©
2.274 3.000 2.500 5.270 .236 HR 170-4-201-1X 232511 170-4-191-1•
2.364-18 Involute Spline
2.364 3.500 3.375 6.350 — HR — — 170-4-1061-1•
2.364-36 Involute Spline
2.364 3.000 2.685 5.470 — HR 170-4-1021-1X• 232200 170-4-1011-1©
2.364 3.000 2.685 6.780 — HR 170-4-791-1X• 232200 170-4-781-1©
High angle yoke
2.364 3.500 2.485 5.270 .306 HR 170-4-1041-1X 232201 170-4-1031-1
2.373-36 Involute Spline
2.373 3.000 2.094 6.040 — HR — — 170-4-1741-1
2.374-46 Spline
2.374 3.250 2.875 5.760 .140 HR 170-4-591-1X 231615 170-4-571-1•
2.374 3.250 2.875 5.760 .140 HR 170-4-581-1X 231179 170-4-571-1•
2.374 3.250 2.875 7.250 .140 HR 170-4-611-1X 231615 170-4-601-1©
High angle yoke
2.374 3.500 2.406 5.880 — HR 170-4-1221-1X 232042-10 170-4-1211-1•
2.374 3.500 2.406 6.688 — HR 170-4-1291-1X 232042-10 170-4-1281-1•
High angle yoke
2.374 3.750 2.406 5.190 — HR 170-4-1191-1X — 170-4-1171-1©
Assy includes electronic speedometer gear #231528
2.390-46 Involute Spline
2.390 2.879 2.750 5.590 .157 HR — — 170-4-1271-1
Coupling shaft yoke
2.390 3.250 2.328 5.100 .140 HR 170-4-03558-1X 5003552 170-4-711-1•
2.390 3.250 2.328 5.100 .140 HR 5003558 5003552 170-4-711-1•
2.390 3.250 2.328 5.100 .140 HR 170-4-721-1X 231803 170-4-711-1•
2.390 3.250 2.328 6.438 .140 HR 170-4-03559-1X 5003552 170-4-731-1©
2.390 3.250 2.328 6.438 .140 HR 170-4-741-1X 231803 170-4-731-1©
High angle yoke
2.390 3.250 2.328 6.438 .140 HR 5003559 5003552 170-4-731-1©
5003559 was replaced by 170-4-03559-1X
2.390 3.250 2.875 5.760 .140 HR — — 170-4-1681-1
2.390 3.375 3.195 6.531 .580 HR 170-4-301-1X 232610 170-4-291-1•
2.500-10 Spline
2.500 3.500 2.406 5.188 — HR 170-4-1351-1X 232042-11 170-4-1341-1•
2.500 3.750 3.000 5.750 — HR 170-4-481-1X 231616 170-4-471-1•
Hub machined for speedometer gear
