END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
45
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1710 SERIES (Continued) E-6.094 (6.190 FOR HR STYLE) D-1.938 USE KIT 5-280X, & 5-675X
FOR HR STYLE USE STRAP KIT 6.5-70-18X
2.390-46 Involute Spline (Continued)
2.390 3.375 3.188 6.000 .580 HR 6-4-7531-1X 231013 6-4-7511-1•
2.390 3.375 3.188 6.000 .580 HR 6-4-9201-1X 232610 6-4-7511-1•
2.390 3.500 3.375 5.750 — BP — — 6-4-4771
2.390 3.500 3.375 5.750 — HR — — 6-4-4771-1
2.422-18 Involute Spline
2.422 3.375 3.000 5.250 .380 BP — — 6-4-3161
2.422 3.375 3.000 5.812 .380 BP 6-4-4751X 231013 6-4-4581
2.422 3.375 3.000 5.812 .380 HR 6-4-4751-1X 231013 6-4-4581-1•
2.423-18 Involute Spline
2.423 3.146 2.047 5.125 — HR — — 6-4-7491-1•
2.450-47 Involute Spline
2.450 3.900 2.428 5.190 .750 BP — — 6-4-8471
2.500-10 Spline
2.500 3.250 3.000 4.875 — BP 6-4-6761X 231179 6-4-2251
2.500 3.250 3.000 5.000 — HR 6-4-6761-1X 231179 6-4-2251-1©
2.500 3.250 3.000 5.750 — BP 6-4-9151X 231179 6-4-9141©
2.500 3.500 2.406 5.156 — BP 6-4-8321X 232042-10 6-4-4421
2.500 3.500 2.406 5.156 — HR 6-4-8321-1X§ 232042-10 6-4-4421-1•
2.500 3.500 2.406 5.156 — HR 6-4-8351-1X 232042-11 6-4-4421-1•
2.500 3.500 3.000 5.750 — BP — — 6-4-4781
2.500 3.750 3.000 5.625 — BP 6-4-6921X 231616 6-4-6611
Hub machined for speedometer gear
2.500 3.750 3.000 5.625 — HR 6-4-6921-1X 231616 6-4-6611-1
Hub machined for speedometer gear
2.500-24 Involute Spline
2.500 3.000 2.422 4.672 — HR — — 6-4-8841-1•
2.544-49 Involute Spline
2.544 3.755 3.000 5.625 — BP 6-4-7041X 231616 6-4-7051
6-4-7051 was replaced by 6-4-7041X; Hub machined for speedometer gear
2.544 3.755 3.000 5.625 — HR 6-4-7041-1X 231616 6-4-7051-1•
Hub machined for speedometer gear
2.544 3.819 2.125 5.570 .120 BP 131442K 5008437 5008452
5008452 was replaced by 6-4-08452X; Attach nut #131095 on Spicer Axle only
2.544 3.819 2.125 5.570 .120 HR 131437K 5008437 5008453
5008453 was replaced by 6-4-08453-1X; Attach nut #131095 on Spicer Axle only
2.544 3.819 2.125 5.570 .120 BP 6-4-08452X 5008437 6-4-10291©
131442K = 5008452 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.125 5.570 .120 BP 5008452 5008437 6-4-10291©
5008452 was replaced by 6-4-08452X; 131442K = 5008452 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.125 5.570 .120 HR 5008453 5008437 6-4-10291-1©
5008453 was replaced by 6-4-08453-1X; 131437K = 5008453 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.125 5.570 .120 HR 6-4-08453-1X 5008437 6-4-10291-1©
131437K = 5008453 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.125 6.260 .120 BP 131439K 5008437 5008449
5008449 was replaced by 6-4-08449X; Attach nut #131095 on Spicer Axle only
2.544 3.819 2.125 6.260 .120 HR 131438K 5008437 5008450
5008450 was replaced by 6-4-08450-1X; Attach nut #131095 on Spicer Axle only
2.544 3.819 2.125 6.260 .120 BP 5008449 5008437 6-4-10311©
5008449 was replaced by 6-4-08449X; 131439K = 5008449 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.125 6.260 .120 BP 6-4-08449X 5008437 6-4-10311©
131439K = 5008449 yoke assy & nut# 131095; Spicer axles only
