END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
41
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1710 SERIES (Continued) E-6.094 (6.190 FOR HR STYLE) D-1.938 USE KIT 5-280X, & 5-675X
FOR HR STYLE USE STRAP KIT 6.5-70-18X
2.143-41 Involute Spline (Continued)
2.143 2.938 2.500 6.125 — BP 6-4-9181X 232604 6-4-7551
High angle yoke
2.143 2.938 2.500 6.125 — BP 6-4-7561X 231028 6-4-7551
High angle yoke
2.143 2.938 2.500 6.125 — HR 6-4-9181-1X 232604 6-4-7551-1©
High angle yoke
2.143 2.938 2.500 6.125 — HR 6-4-7561-1X 231028 6-4-7551-1©
High angle yoke
2.143 2.938 3.000 6.620 .380 BP 131449K 232168 5008446
5008446 was replaced by 6-4-08446X; Attach nut #128049 for Spicer Axles only
2.143 2.938 3.000 6.620 .380 HR 131450K 232168 5008447
5008447 was replaced by 6-4-08447-1X; Attach nut #128049 for Spicer Axles only
2.143 2.938 3.000 6.620 .380 BP 6-4-08446X 232168 6-4-10301©
131449K = 5008446 yoke assy & nut# 128049; Spicer axles only; High angle yoke
2.143 2.938 3.000 6.620 .380 BP 5008446 232168 6-4-10301©
5008446 was replaced by 6-4-08446X; 131449K = 5008446 yoke assy & nut# 128049; Spicer axles only; High angle yoke
2.143 2.938 3.000 6.620 .380 HR 6-4-08447-1X 232168 6-4-10301-1©
131450K = 5008447 yoke assy & nut# 128049; Spicer axles only
2.143 2.938 3.000 6.620 .380 HR 5008447 232168 6-4-10301-1©
5008447 was replaced by 6-4-08447-1X; 131450K = 5008447 yoke assy & nut# 128049; Spicer axles only
2.143 2.938 3.000 6.625 .380 BP 6-4-9191X 232609 6-4-7541
High angle yoke
2.143 2.938 3.000 6.625 .380 BP 6-4-7651X 231028 6-4-7541
High angle yoke
2.143 2.938 3.000 6.625 .380 HR 6-4-9191-1X 232609 6-4-7541-1
High angle yoke
2.143 2.938 3.000 6.625 .380 HR 6-4-7651-1X 231028 6-4-7541-1
High angle yoke
2.143 3.000 2.166 5.380 .310 HR 5002877 5002871 5002876
5002877 was replaced by 6-4-02877-1X; 5002876 was replaced by 6-4-02876-1; High angle yoke
2.143 3.000 2.166 5.380 .310 HR 6-4-02877-1X 5002871 5002876
5002876 was replaced by 6-4-02876-1; High angle yoke
2.149-16 Spline
2.149 2.938 2.500 5.188 — BP 6-4-5061X 231022 6-4-4961•
2.149 2.938 3.000 5.500 .380 BP 6-4-4171X 231028 6-4-2181•
2.149 2.938 3.000 5.500 .380 HR 6-4-4171-1X 231028 6-4-2181-1•
2.149 2.938 3.000 6.625 .380 BP 6-4-5481X 231028 6-4-4591
High angle yoke
2.149 2.938 3.000 6.625 .380 BP 6-4-9841X 232367 6-4-4591
High angle yoke
2.149 2.938 3.000 6.625 .380 HR 6-4-9841-1X 232367 6-4-4591-1•
High angle yoke
2.149 3.000 2.500 4.940 .380 BP — — 6-4-3491
2.170-34 Involute Spline
2.170 3.543 1.889 4.441 — HR — — 5007193©
OEM only
2.178-41 Involute Spline
2.178 3.540 1.874 4.800 .114 HR 5001051• 5001045 5001041•
OEM only
2.178-43 Involute Spline
2.178 3.539 2.047 4.690 .157 HR — — 6-4-8561-1
2.178 3.539 2.047 4.875 .157 SR — — 6-4-9221
2.178 3.539 2.047 4.875 .157 HR — — 6-4-9221-1
