Spicer Driveline Components Catalog - End Yokes - Manual (Page 27)

END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
25
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1480 SERIES (Continued) SR: E-4.438 OTHERS: E-4.188, D-1.375 USE KIT 5-188X, 5-803X
USES U-BOLT ASSY NO.3-94-28X,STRAP ASSY. 3-70-38X
1.567-36 Involute Spline
1.567 1.811 2.000 4.022 — BS — — 3-4-18183-1
Coupling shaft yoke; Hub diameter not ground
1.567 2.156 20.310 4.031 — UB — — 5018183
5018183 was replaced by 3-4-18183-1
1.605-15 Involute Spline
1.605 2.125 1.938 4.000 — BS — — 3-4-9301-1
1.609-37 Involute Spline
1.609 2.500 2.000 4.328 .240 BS 3-4-11281-1X 231872 3-4-11171-1
1.609 2.500 2.000 4.328 .240 BS 3-4-14731-1X• 84406 3-4-11171-1
1.625-10 Spline
1.625 2.375 2.125 4.188 — BS 3-4-5781-1X• 230895 3-4-3141-1©
1.625 2.375 2.125 4.312 — UB — — 3-4-3771•
1.625-26 Involute Spline
1.625 1.938 2.000 4.688 — UB — — 3-4-9031•
1.750-10 Spline
1.750 2.250 2.188 4.250 — BS 3-4-6241-1X• 230895 3-4-6231-1•
1.750 2.250 2.188 4.406 — BS — — 3-4-7361-1
1.750 2.362 2.120 4.215 — BS — — 3-4-13821-1
1.750 2.362 2.125 4.214 — BS — — 3-4-14551-1
1.750 2.375 2.125 4.250 .250 BS — — 3-4-8021-1•
C'bore depth is chamfered
1.750 2.375 2.188 4.219 — BS — — 3-4-3191-1
1.750 2.375 2.188 4.219 — BS — — 3-4-3571-1
1.750 2.500 1.922 3.859 — UB — — 3-4-5911•
1.750 2.500 1.922 5.109 — BS — — 3-4-11561-1
Flanged end yoke, strap kit not furnished by Dana
1.750 2.500 1.938 4.000 — BS — — 3-4-11871-1
1.750 2.500 1.938 4.000 — BS — — 3-4-11871-2
Attaching hardware by OEM
1.750 2.500 1.938 5.750 — BS — — 3-4-7171
Flanged end yoke, strap kit not furnished by Dana
1.750 2.500 1.953 4.000 — BS — — 3-4-9271-1
1.750 2.500 1.953 4.000 — BS — — 3-4-9271-2
Attaching hardware by OEM
1.750 2.500 2.000 4.000 — BS — — 3-4-13901-1
1.750 2.500 2.250 4.281 — BS — — 3-4-6411-1•
1.750 2.625 1.938 3.969 — UB — — 3-4-4051
3-4-4051 was replaced by 3-4-4051-1
1.750 2.625 1.938 3.969 — BS — — 3-4-4051-1•
1.750 2.625 2.188 4.281 .250 BS 3-4-5811-1X 230909 3-4-3391-1•
C'bore depth is chamfered
1.750 2.625 2.188 4.750 .250 BS — — 3-4-10301-1
Flanged yoke w/.250 deep spline chamfer
1.750 2.625 2.250 4.281 .250 BS 3-4-5791-1X 230909 3-4-3061-1
C'bore depth is chamfered
1.750 2.625 2.250 4.469 .250 BS — — 3-4-3121-1
C'bore depth is chamfered
1.750 2.685 2.245 4.276 .250 BS — — 3-4-3541-1
C'bore depth is chamfered
1.750 2.750 2.250 4.281 .500 UB — — 3-4-9621
3-4-9621 was replaced by 3-4-9621-1
1.750 2.750 2.250 4.281 .500 BS — — 3-4-9621-1
