END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
19
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1350 SERIES SR: E-3.875 OTHERS: E-3.625, D-1.188 USE KIT 5-178X, 5-799X
USES U-BOLT ASSY. 3-94-18X, STRAP ASSY. 3-70-28X
.970-29 Involute Spline
.970 1.500 1.500 3.547 .299 BS — — 3-4-11721-1
1.125-10 Spline
1.125 1.552 1.500 3.000 — BS — — 3-4-2111-1
1.146-26 Involute Spline
1.146 1.516 1.969 3.476 — SR 5006148 5004797 5006147
OEM only
1.146 1.550 1.500 3.000 — BS — — 3-4-13761-1
1.146 1.550 1.500 3.000 — BS 3-4-5761-1X 15099 3-4-5751-1©
1.170-10 Involute Spline
1.170 1.375 1.406 2.406 — UB — — 3-4-2801
C'bore depth is chamfered
1.181-10 Spline
1.181 1.875 1.656 3.125 — BS — — 3-4-2051-1
1.194-46 Involute Spline
1.194 2.000 2.203 3.938 — BS — — 3-4-9821-1
1.209-27 Involute Spline
1.209 1.516 1.469 3.250 .290 BS 3-4-11911-1X• 232064 3-4-9941-1•
1.209 1.516 1.469 3.328 .290 BS 3-4-11231-1X• 231636 3-4-11221-1©
1.229-28 Involute Spline
1.229 1.844 1.375 3.031 .120 BS 3-4-11931-1X 231935-1 3-4-11901-1•
Zinc plated slinger
1.250-10 Spline
1.250 1.750 2.000 3.500 — BS — — 3-4-3761-1
1.250 2.125 1.750 3.312 — UB — — 3-4-2781•
1.268-14 Involute Spline
1.268 — 1.790 2.688 — SR — — 3-4-13161
1.276-29 Involute Spline
1.276 1.810 1.495 2.995 — BS — — 3-4-14621-1
Coupling shaft yoke
1.276 1.875 1.500 3.000 — BS 3-4-12781-1X© 34592 3-4-12771-1•
1.276 1.875 1.500 3.000 — BS 3-4-13031-1X• 45799 3-4-12771-1•
1.276 1.875 1.500 3.000 — BS 3-4-13031-2X 45799 3-4-12771-2©
Attaching hardware by OEM
1.276 1.875 1.500 3.000 — BS 3-4-14541-1X© 34592 3-4-14531-1•
OEM only
1.276 1.875 1.500 3.000 — SR — 52392 3-4-14671-1
1.276 1.875 1.500 3.000 — BS — — 3-4-5721-1
Coupling shaft yoke
1.276 1.875 1.500 3.000 — BS 3-4-5731-1X 34592 3-4-5721-1
1.282-15 Involute Spline
1.282 1.810 1.450 3.030 — BS — — 3-4-11421-1
Hub diameter not ground
1.282 1.812 1.600 3.031 — BS — — 3-4-11441-1
Hub diameter not ground
1.282 1.970 2.250 3.875 — BS — — 3-4-13601-1
Hub diameter not ground
1.284-14 Involute Spline
1.284 2.000 1.438 2.688 — SR 3-4-5391X 230859 3-4-5301
1.284 2.000 1.719 2.688 — SR — — 3-4-7401
.375 Dia.set screw @ 6 OR 12, hub diameter not ground.
1.312-30 Involute Spline
1.312 1.938 1.156 3.125 — BS 3-4-8691-1X 231356 3-4-8681-1
