END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
55
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1810 SERIES (Continued) E-7.547 (7.643 FOR HR STYLE) D-1.938 USE KIT 5-281X, 5-676X
FOR HR STYLE USE STRAP KIT 6.5-70-18X
2.544-49 Involute Spline
2.544 3.750 3.000 5.875 — BP 6.5-4-3621X• 231616 6.5-4-3611©
Hub machined for speedometer gear
2.544 3.750 3.000 5.875 — HR 6.5-4-3621-1X 231616 6.5-4-3611-1•
Hub machined for speedometer gear
2.544 3.818 2.141 5.740 .120 BP 131444K 5008437 5008456
Attach nut #131095 on Spicer Axle only
2.544 3.818 2.141 5.740 .120 HR 131443K 5008437 5008457
5008457 was replaced by 6.5-4-08457-1X; Attach nut #131095 on Spicer Axle only
2.544 3.818 2.141 5.740 .120 BP 6.5-4-08456X 5008437 6.5-4-5091©
131444K = 5008456 yoke assy & nut# 131095; Spicer axles only
2.544 3.818 2.141 5.740 .120 BP 5008456 5008437 6.5-4-5091©
131444K = 5008456 yoke assy & nut# 131095; Spicer axles only
2.544 3.818 2.141 5.740 .120 HR 5008457 5008437 6.5-4-5091-1•
5008457 was replaced by 6.5-4-08457-1X; 131443K = 5008457 yoke assy & nut# 131095; Spicer axles only
2.544 3.818 2.141 5.740 .120 HR 6.5-4-08457-1X 5008437 6.5-4-5091-1•
131443K = 5008457 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.677 5.740 — BP 131448K 5008437 5008442
5008442 was replaced by 6.5-4-08442X; Attach nut #131095 on Spicer Axle only
2.544 3.819 2.677 5.740 — BP 5008442 5008437 6.5-4-5101©
5008442 was replaced by 6.5-4-08442X; 131448K = 5008442 yoke assy & nut# 131095; Spicer axles only
2.544 3.819 2.677 5.740 — BP 6.5-4-08442X 5008437 6.5-4-5101©
131448K = 5008442 yoke assy & nut# 131095; Spicer axles only
2.544 3.820 2.692 5.740 .240 HR 131447K 5008437 5008443
5008443 was replaced by 6.5-4-08443-1X; Attach nut #131095 on Spicer Axle only
2.544 3.820 2.692 5.740 .240 HR 5008443 5008437 6.5-4-5101-1•
5008443 was replaced by 6.5-4-08443-1X; 131447K = 5008443 yoke assy & nut# 131095; Spicer axles only
2.544 3.820 2.692 5.740 .240 HR 6.5-4-08443-1X 5008437 6.5-4-5101-1•
131447K = 5008443 yoke assy & nut# 131095; Spicer axles only
2.544 4.000 2.750 5.562 .180 HR — — 6.5-4-3821-1
2.560-20 Involute Spline
2.560 3.500 3.344 6.125 — BP — — 6.5-4-3361
2.560 3.500 3.344 6.125 — HR — — 6.5-4-3361-1
2.631-25 Involute Spline
2.631 3.625 3.000 5.781 1.000 BP — — 6.5-4-2181
2.635-20 Involute Spline
2.635 3.750 2.750 5.562 — BP — — 6.5-4-2011
Hub machined for speedometer gear
2.635 3.750 2.750 5.562 — BP 6.5-4-3541X 231745 6.5-4-3021
Hub machined for speedometer gear; Hub Dia. 3.000 if used on Spicer 1241 Aux. Trans.
2.635 3.750 2.750 5.562 — HR 6.5-4-3541-1X 231745 6.5-4-3021-1§
Hub machined for speedometer gear; Hub Dia. 3.000 if used on Spicer 1241 Aux. Trans.
2.635 3.750 3.312 6.062 .560 BP 6.5-4-2601X• 230888 6.5-4-1941•
2.635 4.000 3.281 6.062 .560 BP 6.5-4-4551X 230888 6.5-4-4541©
2.750-10 Spline
2.750 3.500 3.000 6.062 — BP 6.5-4-2931X 230674 6.5-4-1901
2.750 3.750 3.000 6.062 — BP 6.5-4-3501X 230902 6.5-4-3461•
2.750 3.750 3.000 6.062 — HR 6.5-4-3501-1X 230902 6.5-4-3461-1•
2.750 3.750 3.000 6.062 — BP 6.5-4-3561X 231616 6.5-4-3491•
2.750 3.750 3.000 6.062 — HR 6.5-4-3561-1X 231616 6.5-4-3491-1
2.750 3.875 3.000 6.062 — HR — — 6.5-4-3801-1
Hub diameter not ground
2.750 4.000 2.938 6.000 — BP — — 6.5-4-2171
Hub machined for speedometer gear
2.750 4.000 2.938 6.000 — HR — — 6.5-4-2171-1
Hub machined for speedometer gear
