STEERING SHAFT SERRATED HOLE
With Snap Ring Design
J300P-4
71
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
Serrated Hole H J L L1 S
Major
Diameter
Minor
Diameter
(Nominal)
Bolt Hole
Diameter
Center of
Bolt Hole
to End of
Hub
Top of
Bolt Hole
to End of
Hub
Center of
Bolt Hole
to Center
of Spline
Centerline
to End of
Hub
Centerline
to End of
Hub
End Yoke
Part
Number
1000ST SERIES (Continued) K-1.500 D-.938 USE KIT 5-103X
.990-14 Based On 36 Spline
.990 .947 .451 2.030 .470 .852 — 2.500 10-4-851SX
.994-30 Based On 36 Spline
.994 .947 .405 1.750 .630 .802 — 2.380 10-4-391SX
.994 .947 .405 1.780 .470 .802 — 2.250 10-4-121SX
.994 .947 .405 1.780 .470 .802 — 2.250 10-4-561SX
.994 .947 .405 2.030 .470 .802 — 2.500 10-4-371SX
.994 .947 .405 2.030 .470 .802 — 2.500 10-4-961SX
.994 .947 .451 2.030 .470 .863 — 2.500 10-4-971SX
.994 .947 .451 2.030 .470 .863 — 2.500 10-4-451SX
.994 .947 .451 4.000 .470 .863 — 4.470 10-4-1201SX
.994 .947 .467 2.030 .470 .835 — 2.500 10-4-731SX
1.006-34 Based On 48 Spline
1.006 .960 .468 2.030 .470 — .630 2.500 10-4-661SX
1.014-66 Based On 79 Spline
1.014 — .406 1.970 .380 .835 — 2.340 10-4-1131SX
1.014 .975 .438 1.970 .370 .829 — 2.340 10-4-1441M
1310ST SERIES E-3.469 D-1.062 USE KIT 5-251X
1.000-30 Based On 36 Spline
1.000 .947 4.500 2.120 .760 — .610 2.880 2-4-4411SX
1.000-36 Spline
1.000 .947 .406 2.125 .437 — .610 2.562 2-4-4461SX
