END YOKES with SPLINED HOLES
J300P-4
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger/plug) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
59
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
7C SERIES (Continued) P-5.842 T-1.938 KEYWAY: 0.624 USE KIT 5-7105X
1.775-16 Involute Spline
1.775 2.625 2.250 3.500 — WB — — 7C-4-121
Tapped holes in yoke ears
1.775 2.625 2.250 3.500 — WB — — 7C-4-201•
Flanged yoke w/six, tapped holes in flange
1.796-34 Involute Spline
1.796 2.625 2.094 3.520 .200 WB — — 7C-4-291
Tapped holes in yoke ears
1.922-14 Involute Spline
1.922 2.375 2.188 3.440 .120 WB — — 7C-4-131
Tapped holes in yoke ears
1.922 2.375 2.188 3.690 .120 WB — — 7C-4-141
Tapped holes in yoke ears
1.922 2.375 2.188 3.690 .120 WB — — 7C-4-151M
Metric; Tapped holes in yoke ears
1.922 2.375 2.188 3.690 .120 WB — — 7C-4-311
Tapped holes in yoke ears
1.922 2.375 2.188 3.690 .120 WB — — 7C-4-71
Tapped holes in yoke ears
1.922 2.375 2.188 3.750 — WB — — 7C-4-251
Tapped holes in yoke ears; w/6 tapped holes in flange
1.922 2.375 2.188 4.440 — WB — — 7C-4-241
Flanged yoke w/8 tapped holes in flange
2.005-15 Involute Spline
2.005 2.822 2.500 3.880 .250 WB — — 7C-4-281M
Metric; Tapped holes in yoke ears
2.005 2.822 2.500 3.880 .250 WB — — 7C-4-31
Tapped holes in yoke ears
2.005 2.822 2.500 3.880 .250 WB — — 7C-4-41M
Metric; Tapped holes in yoke ears
2.005 2.875 2.500 3.880 .250 WB — — 7C-4-11
Tapped holes in yoke ears
2.005 2.875 2.500 3.880 .250 WB — — 7C-4-271
Tapped holes in yoke ears
2.005 2.875 2.500 4.880 .250 WB — — 7C-4-191
Tapped holes in yoke ears; w/16 tapped holes in flange
2.005 2.875 2.500 4.880 .250 WB — — 7C-4-351
Tapped holes in yoke ears; w/16 tapped holes in flange
2.008-31 Involute Spline
2.008 — 2.750 4.209 .750 WB — — 7C-4-471M
Metric; Tapped holes in yoke ears; Hub dia. not ground
2.289-17 Involute Spline
2.289 2.750 2.500 4.190 — WB — — 7C-4-101
Tapped holes in yoke ears
2.289 2.750 2.500 4.190 — WB — — 7C-4-111
2.289 2.750 2.500 4.190 — WB — — 7C-4-91
Tapped holes in yoke ears
2.289 2.750 2.500 4.440 — WB — — 7C-4-161
Flanged WB yoke w/tapped holes in yoke ears
2.289 2.750 2.500 4.440 — WB — — 7C-4-321
Flanged WB yoke w/tapped holes in yoke ears
2.372-46 Involute Spline
2.372 — 3.385 4.705 .500 WB — — 7C-4-401M
Metric; Tapped holes in yoke ears
