End yokes with splined holes – Spicer Driveline Components Catalog - End Yokes User Manual
Page 15
END YOKES with SPLINED HOLES
J300P-4
R
Location
S
Spicer
Major
Set Screw
Pin Hole
Viewed
Centerline
Part
Diameter
Hub Dia.
Diameter
Diameter
From Hub
to End of Hub
Number
13
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
1000 SERIES
K-1.500 D-.938 USE KIT 5-170X
.875-13 Spline
.875
1.500
.250
—
6
3.812
10-4-641
.875
1.625
.375
—
6
2.500
10-4-481
1.000-6 Spline
1.000
1.625
.375
—
3
2.500
10-4-101
.375 Dia. set screw @ 3 or 9
1.125-6 Spline
1.125
1.625
—
.328
THRU HUB
2.500
10-4-11
.328 dia. pin hole thru hub
1.250-6 Spline
1.250
1.625
—
.328
THRU HUB
2.500
10-4-21
.328 dia. pin hole thru hub
1.375-6 Spline
1.375
2.000
—
.328
THRU HUB
2.500
10-4-31
.328 dia. pin hole thru hub
