Spicer Driveline Components Catalog - End Yokes - Manual (Page 23)

END YOKES with SPLINED HOLES
R Q S End Yoke Assy. Slinger/Plug Spicer
Major Ground Length Centerline C'Bore Style (includes slinger) Part Part
Diameter Hub Dia. Thru Hole to End Depth Order When Listed Number Number
21
Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued  Part is available until supply is exhausted © Not sold separately
J300P-4
1350 SERIES (Continued) SR: E-3.875 OTHERS: E-3.625, D-1.188 USE KIT 5-178X, 5-799X
USES U-BOLT ASSY. 3-94-18X, STRAP ASSY. 3-70-28X
1.511-14 Involute Spline
1.511 2.125 2.531 4.500 — BS — — 3-4-8501-1
1.511 2.375 1.828 3.312 — BS — — 3-4-8491-1•
1.625-10 Spline
1.625 2.375 2.125 3.969 — UB 3-4-9001X• 230895 3-4-3931•
1.625 2.375 2.125 3.969 — BS 3-4-9001-1X• 230895 3-4-3931-1•
1.750-10 Spline
1.750 2.375 1.812 3.500 — BS — — 3-4-3801-1
1.750 2.375 2.188 4.000 — BS — — 3-4-2351-1
1410 SERIES SR: E-4.438 OTHERS: E-4.188, D-1.188 USE KIT 5-160X, 5-801X
USES U-BOLT ASSY, 3-94-18X, STRAP KIT 3-70-28X
1.250-10 Spline
1.250 1.875 1.500 3.188 — BS 3-4-4451-1X 30798 3-4-4441-1©
1.260-23 Involute Spline
1.260 1.565 1.609 3.562 .360 BS — — 3-4-10941-1
1.268-14 Involute Spline
1.268 1.516 1.750 2.750 — SR — — 3-4-5321
Hub diameter not ground
1.268 2.250 2.125 4.031 — BS 3-4-9561-1X 2-68-293 3-4-9551-1
w/zerk fitting
1.268 2.375 2.250 4.031 — BS — — 3-4-7721-1
.375 Dia.set screw @ 6 OR 12, hub diameter not ground.
1.276-29 Involute Spline
1.276 1.810 1.500 3.200 — BS — — 3-4-14591-1
Coupling shaft yoke
1.276 1.874 1.420 3.185 — BS 3-4-11891-1X 34592 3-4-11851-1
1.276 1.875 1.500 3.188 — BS 3-4-5711-1X 34592 3-4-5701-1•
1.276 1.875 1.500 3.188 — BS — — 3-4-8731-1
1.276 1.875 1.500 3.200 — BS 3-4-14711-1X 52392 3-4-14681-1©
Attaching hardware by OEM
1.375-10 Spline
1.375 1.719 1.781 3.469 — BS 3-4-2851-1X 98-1473 3-4-2841-1•
Hub diameter not ground
1.375 1.719 2.000 3.703 — BS — — 3-4-1471-1
1.375 1.875 1.688 3.500 — BS 3-4-12541-1X• 2-68-164 3-4-12531-1©
1.375 1.938 2.000 3.688 — BS — — 3-4-1481-1
1.375 2.125 2.000 3.685 — BS — — 3-4-2271-1
1.375 2.500 1.938 5.750 — BS — — 3-4-7141
Flanged end yoke, strap kit not furnished by Dana
1.375-32 Involute Spline
1.375 1.886 2.000 3.675 — BS — — 3-4-13511-1
Uses GM brg. strap
1.383-21 Involute Spline
1.383 2.625 3.312 4.641 1.190 BS — — 3-4-11471-1
1.400-32 Involute Spline
1.400 2.125 2.000 3.688 — BS — — 3-4-10951-1
1.498-29 Involute Spline
1.498 1.969 1.828 3.938 — BS — — 3-4-10571-1•
1.498 2.000 1.609 3.688 — BS — — 3-4-10931-1•
