END YOKES with SPLINED HOLES
J300P-4
R
Q
S
End Yoke Assy.
Slinger/Plug
Spicer
Major
Ground
Length
Centerline C'Bore Style
(includes slinger)
Part
Part
Diameter Hub Dia. Thru Hole
to End
Depth
Order When Listed
Number
Number
40
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued Part is available until supply is exhausted
©
Not sold separately
1710 SERIES (Continued) E-6.094 (6.190 FOR HR STYLE) D-1.938
USE KIT 5-280X, & 5-675X
FOR HR STYLE USE STRAP KIT 6.5-70-18X
2.024-39 Involute Spline (Continued)
2.024
2.625
2.250
6.125
.250
BP
6-4-6021X
230909
6-4-6011©
High angle yoke; Chamfered Counterbore
2.024
2.625
2.250
6.125
.250
HR
6-4-6021-1X
230909
6-4-6011-1©
High angle yoke; Chamfered Counterbore
2.024
2.625
2.250
6.125
.250
BP
6-4-8541X
232167
6-4-7981
High angle yoke
2.024
2.625
2.250
6.125
.250
HR
6-4-8541-1X
232167
6-4-7981-1•
High angle yoke
2.024
2.625
2.500
5.250
.250
BP
6-4-9041X
232514
6-4-8441
2.024
2.625
2.500
5.250
.250
HR
6-4-9041-1X
232514
6-4-8441-1
2.024
2.625
2.500
6.125
.250
BP
6-4-9001X
232514
6-4-8431
2.024
2.625
2.500
6.125
.250
HR
6-4-9001-1X
232514
6-4-8431-1
2.024
3.000
2.250
4.656
.280
HR
6-4-9431-1X
232200
6-4-9421-1•
2.024
3.000
2.250
4.656
.280
HR
6-4-9441-1X•
232199
6-4-9421-1•
2.024
3.000
2.250
6.000
.280
HR
6-4-9301-1X
232200
6-4-9291-1©
High angle yoke
2.024
3.000
2.281
5.250
.250
BP
6-4-9031X
232511
6-4-8421
2.024
3.000
2.281
5.250
.250
HR
6-4-9031-1X
232511
6-4-8421-1
2.024
3.000
2.281
6.125
.250
BP
6-4-8991X
232511
6-4-8411
High angle yoke
2.024
3.000
2.281
6.125
.250
HR
6-4-8991-1X
232511
6-4-8411-1
2.024
3.000
2.500
6.120
.280
HR
—
—
6-4-9281-1
2.032-10 Spline
2.032
2.750
2.000
5.000
.120
BP
—
—
6-4-3791
2.032
2.750
2.391
5.375
.500
BP
—
—
6-4-2431
2.114-32 Involute Spline
2.114
3.000
2.250
4.562
.424
BP
6-4-7221X
231750
6-4-5811•
2.114
3.000
2.250
4.562
.424
HR
6-4-8681-1X
232200
6-4-8671-1
2.114
3.000
2.250
6.062
.424
HR
6-4-8761-1X
232200
6-4-8751-1•
High angle yoke
2.114
3.000
2.250
6.250
.424
BP
6-4-7171X
231750
6-4-5791
High angle yoke
2.126-33 Involute Spline
2.126
3.000
2.500
4.562
—
BP
—
—
6-4-5471
2.143-41 Involute Spline
2.143
2.938
2.500
5.190
—
BP
6-4-9171X
232604
6-4-7311•
2.143
2.938
2.500
5.190
—
HR
6-4-9171-1X
232604
6-4-7311-1
2.143
2.938
2.500
5.190
—
HR
6-4-7321-1X
231028
6-4-7311-1
