Gas sampling and gas conditioning technology
2-1.1.4-ME
12.2 TEMPERATURE REGULATOR
On version SP2000
–H320/S the temperature regulation is effected by the capillary thermostat
mounted inside the connecting box. The range of regulation is from 50 to 320°C.
On the versions SP2000-H320/S1 and SP2000-H320/S2 the regulation is made by means of an ex-
ternal electronic regulator. M&C supplies appropriate temperature regulators, eg. Type 703G (see
data sheet 2-5.1) or Type 703G double that can be mounted separately or directly on the gas sample
probe (max. ambient temperature +45°C).
12.3 SCOPE OF SAMPLING TUBES AND PREFILTERS
Depending on the process gas temperature and composition, sample tubes of different materials with
connector G ¾” are applicable:
Selection of materials
Type
Max. process
temperature
Max. length
Outside tube diameter
(sleeve or adapter)
Stainl. Steel 1.4571
SS
600 °C
2,5 m *
25 (37)mm
Titanium
Ti
400 °C
2,5 m *
25 (37)mm
Hastelloy
HC
900 °C
2,5 m *
25 (37)mm
Inconel
IN
1100 °C
2,0 m *
25 (37)mm
Chrome-Aluminium
oxide
CR
1400°C
1,2m
23 (37)mm
Kanthal
Ka
1300 °C
2,5 m *
25 (37)mm
Aluminium-Oxide
AO
1800 °C
1,5 m *
25 (55)mm
PVDF
PV
90 °C
1,5 m *
25 (37)mm
PTFE
T
160 °C
0,5 m
33mm
Incoloy
IC
1200 °C
2,0 m *
25 (37)mm
*Standard = 1m
Further information on sampling tubes see data sheet 2-1.1.0.6
In case gas has to be sampled behind wet washers, the Demister sampling tube of PVDF with con-
nector G ¾” has to be applied in order to evacuate the droplets:
Type
Max.
Process temperature
Max. length
Outside diameter of the
tube
SP32
90 °C
0,8 m *
50mm
*Standard
In order to avoid condensation between the sampling point and the heated gas sample probe or con-
densation in the area of the connection piece, heated sample tubes have to be applied made of
stainl. Steel with flange connection DN65 PN6.
Type
Max. Process
temperature
Max.
length
Outside tube diameter
SP30-H1.1, heating max. 320°C
550 °C
2,0 m *
42,4mm
SP30-H1.1V, heating max. 320°C
550 °C
1 m
42,4mm
SP30-H2, heating max. 320°C
350 °C
2,0 m *
42,4mm
SP35H.1, heating max. 320°C
550 °C
0,175 m
42,4mm
SP35H.2, heating max. 320°C
350 °C
0,175 m
42,4mm
*Standard = 1m
