6.11
Embracing Challenge
ƒ ƒ
Save continuous condensate removal
ƒ ƒ
With return stop
ƒ ƒ
Self-suctioning
ƒ ƒ
Slow speed
ƒ ƒ
Hose with long service life
ƒ ƒ
Explosion proof version according to
ATEX and NEPSI for zone 1
Special Features
Peristaltic Pump Series SR25®
Peristaltic Pump Series SR25®
SR25.1
Application
The peristaltic pump SR25.1 has been spe-
cially developed for the condensate removal
in analysis applications. It ensures a continu-
ous condensate discharge in gas coolers, con-
densate collecting vessels, etc. A synchronous
motor and the gearing unit with return stop
make a condensate flow back impossible.
The capacity of 0,3 l/hr guarantees a safe con-
densate removal, for example when cooling
850 l/hr sample gas with an initial dew point
of +70 °C.
Description
The peristaltic pump SR25.1 is self-suctioning
and designed for continuous operation. It
consists of 3 compact parts:
• synchronous motor
• gearing unit with return stop
• pump
The slow speed (5 rpm), the two PVDF hose
contact pulleys and the novoprene hose
guarantee a good mechanical and chemical
resistance with a long service life. A pos-
sible change of hoses is simplified by using
specially designed hose sets. The tube con-
nectors DN 4/6 allow as well the application
of PTFE tube.
• The peristaltic pump SR25.1... is sup-
plied with electric mains for 230V/50Hz
and 115V/60Hz.
• The peristaltic pump SR25.1... is designed
as a mounting version.
• Up to 4 peristaltic pumps SR25.1 can be
installed in the compressor gas cooler
type EC and in the universal unit EC-FD
or EC-D (see data sheet 6.5 and 6.6).
• The peristaltic pump SR25.2-G is sup-
plied in a wall mounting case.
• The peristaltic pump SR25.1/Ex is a
mounting version for use in hazardous
area zone 1.
Technical specifications and illustrations are without
obligation, subject to modifications. 09.96/06.06
