14.4
Embracing Challenge
ƒ ƒ
Low maintenance and self-monitoring
ƒ ƒ
Outlet dew point adjustable from +2 °C
to +15 °C
ƒ ƒ
Dew point stability ± 0,1 °C
ƒ ƒ
Operational in 10 minutes
ƒ ƒ
Compact construction
ƒ ƒ
Light weight
ƒ ƒ
Optimum reliability
Special Features
Portable Gas Conditioning Unit
series CSS®
Portable version CSS-M for 70 Nl/h gas flow rate
Wall mounting version CSS-M/W for 70 Nl/h gas flow rate
CSS-M
Application
The M&C portable gas conditioning unit
CSS-M is designed to carry out precise
gas analyses at different locations. The version
CSS-M/W is a complete pre-installed compact
continuous working gas conditioning system
for wall mounting.
Both gas conditioning units are housed in a
robust aluminium-frame case to enable the
user to carry out respectively install a rapid
gas analysis, which is safe with little mainte-
nance work.
The CSS-M gas conditioning unit is suitable
for variable, discontinuous use as well as for
continuous operation.
The components built into the CSS-M and
CSS-M/W gas conditioning units can be used
for standard applications.
Description
The CSS-M and CSS-M/W gas conditioning
units are equipped with an peltier gas cooler
series ECP with Jet-Stream heat exchanger
which cools the sample gas to constant +5
°C independent of the ambient temperature.
As soon as the operating temperature of <
+8 °C is reached after start-up, the gas pump
N3KPE is switched on automatically via the
status contact of the gas-cooler. The SR 25.2
peristaltic pump ensures a constant con-
densate removal which makes a long-term
measurement possible without problems.
The corresponding particle filtration is carried
out by a 2µm filter type FPF-2-0,3GF with an
integrated liquid alarm. In case of alarm the
gas pump is switched off. In the sample gas
outlet a flow meter FM40 is integrated. For
the version CSS-M/W a flow alarm is available
as an option.
This makes both versions complete gas con-
ditioning systems suitable for most of the
analysers.
