Issue 10.01.I EVS Multicam Version 10.01 – Configuration Manual
EVS Broadcast Equipment SA – October 2009
70
3.16.7 ID T
YPE
Possible values: ID LSM (default) / UmID
Defines the type of clip ID used by RS422 protocols (XtenDD35, Odetics, Louth
VDCP, EVS AVSP) to identify clips:
• ID LSM: It identifies clips using their page, bank, clip and camera number (ex:
245C).
• UmID: It is another identifier that is either assigned by the protocol when
creating the clip (ex: CLP00001), or defined automatically by Multicam when
the clip is created using the EVS Remote Panel, or when the protocol doesn’t
specify this ID.
When it is defined by Multicam, the UmID is a coded ID (ex: 3x2QogRW) that is
unique for every clip created on any server, and is based on the serial number
of the server, and creation date and time of the clip.
3.17 SPECIAL CONTROL SETTINGS
Special Control Settings p.7.2
Main RS422 Second. RS422
PGM1: EVS Remote -- [F5]Sony BVW75 04
PGM2:[F2]EVS Remote –- [F6]Sony BVW75 05
PGM3:[F3]EVS Remote –- [F7]---------- --
PGM4:[F4]EVS Remote –- [F8]---------- --
[Menu]Quit [Clr+F_]Dft [F9]PgUp [F0]PgDn
This page is used to define which device/controller can control which PGM
channel. For each PGM channel, you must define the main controller, selecting
from the list defined on page 7.1.
• In LSM mode, the main controller for PGM1 must always be an EVS Remote.
This can not be changed by the operator.
• If the main controller is an EVS Remote, the RS422 port will be automatically
assigned and is not specified by the operator.
• If the main controller is an EVS remote, it is then possible to specify a
secondary controller for that channel, that can be a protocol defined on page
7.1. The EVS remote controlling that channel can then decide at any time to
pass the control to, or to retrieve the control from the secondary controller.
• Like for page 7.1, all EVS remotes must be the first in the list of Main
controllers, without gap. It is not allowed to have a protocol preceding an EVS
remote in this list.
• A protocol (other than EVS AVSP or EVS IPDP protocols) can only be assigned
to 1 channel at a time.
