EVS Multicam Version 10.01 – Configuration Manual

EVS Broadcast Equipment SA – October 2009

Issue 10.01.I

53

3.9.8 K

EYWORD

M

ODE

Possible values: List (default), Numeric

This parameter specifies the keyword assignment/search mode on the EVS
Remote Panel:

List: It will display the keywords by groups of 8 on the LCD of the Remote
Panel and the operator can select them with the corresponding F_ key.

Numeric: It doesn’t display the keywords list on the LCD, but allows the
operator to enter directly the keyword ID using the F_ keys. The Numeric mode
is faster when the operator knows the position of the keywords inside the
keywords file, either from memory, using the VGA keyword screens, or using a
print of the keywords list.

3.9.9 PUSH

M

ACHINE

1

&

2

Possible values: network system name and number. Default: -------- #--

This parameter specifies which machine(s) on the network clips must be sent to
when using the PUSH function on the EVS Remote Panel. Users can define two
push machines: (F3): PUSH Machine 1, (F4): PUSH Machine 2. The clips will be
pushed in sequential order.

3.9.10 PUSH

M

ODE

Possible values: Short, Long

This parameter specifies how the clips should be sent using the PUSH function:

Short: The clips are sent from the Short IN to the Short OUT points, to which
the guardbands of the destination machine are added.

Long: The clips are sent from the Protect IN to the Protect OUT.

3.9.11 PUSH

R

ECEIVE

P

AGE

Possible values: Select one or more clip pages from 1 to 10. Default: p.5

This parameter specifies the page of your machine where clips sent to you by
other network operators using the PUSH function must be stored.

How to Specify PUSH Receive Page(s)

To specify the page(s) to which the clips pushed from another network operator
will be stored, proceed as follows:
