EVS MulticamLSM Version 10.01 - October 2009 Configuration Manual - Manual (Page 36)

EVS Multicam Version 10.01 – Configuration Manual
EVS Broadcast Equipment SA – October 2009
Issue 10.01.I
29
2.8.2 S
ETTINGS
D
ESCRIPTION
The HCTX Gigabit connection settings are described in the table below:
Port #1 / Port #2
IP Address Specifies the IP address to connect to port 1 / port 2 of the
Gigabit Ethernet connection on the server. The IP addresses
0.0.0.0 and 255.255.255.255 are not allowed.
Subnet Mask Specifies the range of logical addresses within the address
space assigned to the Gigabit Ethernet network.
In the screenshot, the logical addresses available within the
network are from 128.1.254.1 to 128.1.254.254.
Default Gateway Specifies the IP address of the router on the Gigabit
Ethernet network that serves as an access point to external
networks.
FTP Login
User name Specifies the user name for an FTP access to the server via
the Gigabit Ethernet connection.
Password Specifies the password for an FTP access to the server via
the Gigabit Ethernet connection. The password is not hidden.
Note
The modifications of parameter values in this screen are not applied
when you leave the field. You need to select the APPLY option at the
bottom right of the screen and press ENTER to apply the modifications.
2.9 LAN CONNECTION SETTINGS (PAGE 6)
2.9.1 I
NTRODUCTION
The settings for the connection with the MTPC board are defined in the Setup
Configuration module, on page 6.
This will allow interaction between the LAN and the MTPC board for the purpose
of system maintenance. The MTPC board and another workstation on the XNet
network will communicate through telnet or FTP access.
