Issue 10.01.I EVS Multicam Version 10.01 – Configuration Manual
EVS Broadcast Equipment SA – October 2009
42
3.3 HOW TO ACCESS THE SETUP MENU
To access the Setup menu, proceed as follows:
1. If you are in Playlist mode, press RECORD first to exit this mode.
2. Press SHIFT + MENU key to go to the Main menu:
Split Paint Target Setup
1PGM+PRV 2/3 PGM
3. Select Setup by pressing SHIFT + D to enter the Setup menu.
The Setup menu is divided in sections (clips, playlists, special effects,
audio, control, GPI, etc.) When entering the setup, a menu presents these
sections.
4. To access a section, press the corresponding F_ key.
3.4 HOW TO NAVIGATE IN THE SETUP MENU
LSM Setup Menu Main page
[F1]OSD Settings [F6]EVS Controller
[F2]Record Trains [F7]RS422 Control
[F3]Clips [F8]GPI
[F4]Playlist [F9]Special Effects
[F5]Audio Clr+[F0]Restore Defaults
[Menu]Quit [Clr+F_]Default [F0]PgDn
The navigation within the Setup menu follows the following principles:
• To move to the previous/next page inside a section, use F9 and F10.
• To more directly to another section when you are inside a section, press SHIFT
+ F_ key corresponding to the section to access.
• To move from a section to the next one, press F10 when you reach the last
page of a section. You will access the first page of the next section. By starting
on the first page and pressing F10, the operator goes through all pages: p.1.1
Æ
p.2.1 Æ p.2.2 Æ…
• To move from a section to the former one, press F9 when you reach the first
page of a section. You will access the last page of the previous section.
