Issue 10.01.I EVS Multicam Version 10.01 – Configuration Manual
EVS Broadcast Equipment SA – October 2009
30
The XNetMonitor will use the LAN IP connection to transfer the moniroting data.
2.9.2 S
ETTINGS
D
ESCRIPTION
The MTPC board connection settings are described in the table below:
Port #1
IP Address Specifies the IP address to connect to the port 1 of the
MTPC board on the server. The IP addresses 0.0.0.0 and
255.255.255.255 are not allowed.
Subnet Mask Specifies the range of logical addresses within the address
space assigned to the MTPC board connection.
Default Gateway Specifies the IP address of the router on the XNet network
that the MTPC board can use as an access point to external
networks.
Note
The modifications of parameter values in this screen are not applied
when you leave the field. You need to select the APPLY option at the
bottom right of the screen and press ENTER to apply the modifications.
