HDMI_SPDIF Header
HDMI_SPDIF header, providing
(2-pin HDMI_SPDIF1)
SPDIF audio output to HDMI
(see p.4 No. 39)
VGA card, allows the system to
connect HDMI Digital TV/
projector/LCD devices. Please
connect the HDMI_SPDIF
connector of HDMI VGA card to
this header.
V-Probe
TM
Users are able to measure
(7-pin VOL_CON1)
onboard components voltage,
(see p.4 No. 9)
including VCORE, VCCSA,
DRAM_CD, DRAM_AB and
VTT.
GND
VCORE
VCCSA
DRAM_CD
DRAM_AB
GND
VTT
