Prestige 324 Intelligent Broadband Sharing Gateway
LAN Setup 4-7Wizard Setup
Table 4-4 PPPoE Encapsulation
FIELD DESCRIPTION
ISP Parameter for Internet Access
Encapsulation
Choose an encapsulation method from the pull-down list box. PPPoE forms a dial-up
connection.
Service Name
(Optional)
Type the name of your service provider.
User Name Type the user name given to you by your ISP.
Password Type the password associated with the user name above.
Nailed Up
Connection
Select Nailed Up Connection if you do not want the connection to time out.
Idle Timeout
Type the time in seconds that elapses before the router automatically disconnects from
the PPPoE server. The default time is 100 seconds.
To continue, click Next.
To return to the previous screen, click Back.
4.3 Wizard Setup: Screen 3
4.3.1 WAN IP Address Assignment
Every computer on the Internet must have a unique IP address. If your networks are isolated from the
Internet, for instance, only between your two branch offices, you can assign any IP addresses to the hosts
without problems. However, the Internet Assigned Numbers Authority (IANA) has reserved the following
three blocks of IP addresses specifically for private networks.
